Chain With Hooks

These chain with hooks can be widely used for fixing and towing heavy objects and so on .Chains with different diameters have different load-bearing capacity.You can select the appropriate specifications according to your own needs .

Send Inquiry PDF DownLoad

Product Description

Chain With Hooks Introduction

These steel chains can be widely used for fixing and towing heavy objects and so on .Chains with different diameters have different load-bearing capacity.You can select the appropriate specifications according to your own needs .

Chain With Hooks Specification

Nominal size		Material diamerter	working load limit		proof test		breaking force minimum		max length per 100links	max length per 100feet
Nominal size		mm	lbs	kgs	lbs	kn	lbs	kn	m	kgs
7	1/4	7	1180	2800	17.3	3900	34.6	7800	31.5	9.8
8.7	5/16	8	1770	3900	26	5850	52	11700	32.8	11.2
10	3/8	10	2450	5400	36	8100	72	16200	35	14
13	1/2	13.5	4170	9200	61.3	13800	122.6	27600	45.5	18.2

Nominal size		Material diamerter	working load limit		proof test		breaking force minimum		max length per 100links	max length per 100feet
Nominal size		mm	lbs	kgs	lbs	kn	lbs	kn	m	kgs
7	1/4	7	1430	3150	28	6300	56	12600	31.8	9.8
8.7	5/16	8	2130	4700	41.8	9400	83.6	18800	32.8	11.2
10	3/8	10	2990	6600	58.7	13200	117.4	26400	35	14
